Pentax CM65 Series
Surface Mounted Flanged EN733 Centrifugal Pumps
Pentax CM65 Pump Series Single Stage Monobloc Centrifugal Pumps
Pentax CM65-125A, CM65-125B, CM65-160A, CM65-160B, CM65-160C, CM65-200A, CM65-200B, CM65-200C, CM65-250A and CM65-250B. Centrifugal Single Stage Monobloc Pumps Surface Mounted Pumps. Monobloc horizontal centrifugal pumps, constructed to EN 733 standards; widely used in water supplies, pressurisation and fire-fighting systems, cooling, heating, irrigation, industrial and agricultural applications; standard supply with counter-flange.
Construction Features
Pump body - cast iron
Motor bracket - cast iron
Impeller - cast iron, bronze or stainless steel
Seal - ceramic-graphite-NBR
Mechanical seal - steel AISI 304
Ambient temperature - 0 - 10 ÷ + 90°C
Pump body gasket - max 10 bar
Motor
2 poles induction motor - 3~ 230/400V-50Hz P 4kW, 3~ 400/690V-50Hz P > 4kW, 1-230V-50Hz
Insulation class - F
Protection degree - IPX5
For prices and specifications click on models below
Pentax CM65-125A Pump Single Stage Centrifugal Pump
HP 10
kW 7,5
Voltage 3 ~ 400/690v
Amp 3 x 400v 15,9
Pentax CM65-125B Pump Single Stage Centrifugal Pump
HP 7.5
kW 45,5
Voltage 3 ~ 400/690v
Amp 3 x 400v 12,3
Pentax CM65-160A Pump Single Stage Centrifugal Pump
HP 20
kW 15
Voltage 3 ~ 400/690v
Amp 3 x 400v 30
Pentax CM65-160B Pump Single Stage Centrifugal Pump
HP 15
kW 11
Voltage 3 ~ 400/690v
Amp 3 x 400v 22.5
Pentax CM65-160C Pump Single Stage Centrifugal Pump
HP 12.5
kW 9
Voltage 3 ~ 400/690v
Amp 3 x 400v 19.5
Pentax CM65-200A Pump Single Stage Centrifugal Pump
HP 30
kW 22
Voltage 3 ~ 400/690v
Amp 3 x 400v 51.5
Pentax CM65-200B Pump Single Stage Centrifugal Pump
HP 25
kW 18,5
Voltage 3 ~ 400/690v
Amp 3 x 400v 41,5
Pentax CM65-200C Pump Single Stage Centrifugal Pump
HP 20
kW 15
Voltage 3 ~ 400/690v
Amp 3 x 400v 32,5
Pentax CM65-250A Pump Single Stage Centrifugal Pump
HP 50
kW 37
Voltage 3 ~ 400/690v
Amp 3 x 400v 74,5
Pentax CM65-250B Pump Single Stage Centrifugal Pump
HP 40
kW 30
Voltage 3 ~ 400/690v
Amp 3 x 400v 63,5
